亚陶diodes晶振ECERA品牌UF3242DA0100.000000超低抖动晶体振荡器XO
UF324/34
2.5V/3.3V、3.2x2.5mm、超低抖动HCLS晶体振荡器
描述亚陶晶振ECERA品牌,UF3242DA0100.000000,XO晶振
UF324/UF34XO系列是经过优化的晶体振荡器系列,可节省电路板空间.该系列由具有超低抖动性能的高性能HCSL晶体振荡器组成,可满足严格的芯片组要求.它支持多种选择,包括更宽的频率范围、2.5V/3.3V电压和各种稳定性.百利通亚陶晶振它
旨在满足通信系统和其他高性能设备的时钟源规范.

FD1940004	Diodes	FD	19.44MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2000046 OSC晶振	Diodes	FD	20MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2000048	Diodes	FD	20MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2000049	Diodes	FD	20MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2400022	Diodes	FD	24MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2400023	Diodes	FD	24MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2400024	Diodes	FD	24MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2450018	Diodes	FD	24.576MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2450019	Diodes	FD	24.576MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2500049	Diodes	FD	25MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2500052	Diodes	FD	25MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2500054	Diodes	FD	25MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2500057	Diodes	FD	25.0012MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2500058	Diodes	FD	25MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2500061	Diodes	FD	25MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2600027	Diodes	FD	26MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2600028	Diodes	FD	26MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2600030	Diodes	FD	26MHz diodes品牌亚陶晶振	±50ppm	-40°C ~ 85°C	4	5032
FD2600031	Diodes	FD	26MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2660003	Diodes	FD	26.66MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2700033	Diodes	FD	27MHz	±25ppm	-20°C ~ 70°C	4	5032
FD2700034	Diodes	FD	27MHz	±50ppm	-40°C ~ 85°C	4	5032
FD2700035	Diodes	FD	27MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2700038	Diodes	FD	27MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2700043	Diodes	FD	27MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2860005	Diodes	FD	28.6363MHz	±50ppm	-20°C ~ 70°C	4	5032
FD2860006	Diodes	FD	28.63636MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3000014	Diodes	FD	30MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3000015	Diodes	FD	30MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3000016	Diodes	FD	30MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3120001	Diodes	FD	31.25MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3300021	Diodes	FD	33MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3300022	Diodes	FD	33MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3300023	Diodes	FD	33MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3330016	Diodes	FD	33.333MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3330017	Diodes	FD	33.333MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3330018	Diodes	FD	33.3333MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3330019	Diodes	FD	33.3333MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3330020	Diodes	FD	33.3333MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3330022	Diodes	FD	33.333MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3330024	Diodes	FD	33.333333MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3330026	Diodes	FD	33.333MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3430001	Diodes	FD	34.368MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3530003	Diodes	FD	35.328MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3530004	Diodes	FD	35.328MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3530005	Diodes	FD	35.328MHz	±50ppm	-40°C ~ 85°C	4	5032
FD3600009	Diodes	FD	36MHz 台湾有源晶振	±25ppm	-20°C ~ 70°C	4	5032
FD3680001	Diodes	FD	36.864MHz	±50ppm	-20°C ~ 70°C	4	5032
FD3680002	Diodes	FD	36.864MHz	±25ppm	-20°C ~ 70°C	4	5032
FD3680003	Diodes	FD	36.864MHz	±50ppm	-40°C ~ 85°C	4	5032

特征
亚陶晶振ECERA品牌,UF3242DA0100.000000,XO晶振超低相位抖动
0.06ps典型值.0.08psRMS最大值.12kHz至20MHz
扩展温度范围高达125oC
完全无铅且完全符合RoHS标准
不含卤素和锑.”绿色”设备
对于需要特定变更
控制的汽车应用即符合AEC-Q100/101/200、
PPAP并在IATF16949
认证设施中制造的零件
亚陶晶振应用程序
网络系统
光?？?br /> 服务器和存储系统
专业视频设备
测试与测量
FPGA/ASIC时钟生成
112G串行应用

diodes品牌亚陶晶振,有源晶振产品参数
稳定性(PPM)   20到100
包装尺寸毫米         3.2x2.5x0.9
包装类型         陶瓷缝
频率范围(MHz)       100至212.5
抖动均方根(ps)       0.08至0.09
输出逻辑         HCSL
有源晶振电源电压(V)    3.3、2.5
垫     6
产品系列         UF3
